MANGALAM® E310L-16

Application

Rutile type basic coated all position welding electrode for welding of AISI 310 containing 25% chromium and 20% Nickel, low spatter loss, smooth and uniform bead having easy slag removal properties, The weld deposited has excellent resistance to heat and oxidation which is very useful in fabricating furnace components, burners, heat treatment pots & baskets.

Category:

Description

Typical Weldmetal Chemistry %
Carbon 0.08 – 0.20
Manganese 1.0 – 2.50
Silicon 0.75 Max
Chromium 25 – 28
Nickel 20 – 22.5
Typical Mechanical Properties
 Ultimate Tensile Strength 520 N/mm²Min
Elongation 30% Min
Current (AMP)

AC/DC (+)

Other Details



Packing Specification
Size (mm) Current (AMP) Size (mm) Weight Weight
2.50 x 350 40 – 80  2.50 x 350 2 kg 10kg./5pkt
 3.15 x 350 60 – 100  3.15 x 350 2 kg 10kg./5pkt
4.00 x 350  90 – 140  4.00 x 350 2 kg 10kg./5pkt
  5.00 x 350  130 – 180  5.00 x 350 2 kg 10kg./5pkt
